Benefits of Pressure Filters for Industrial Water

Posted by Anthony DeLoach, President on Jan 4, 2022 1:00:00 PM

Industrial water systems often use water filters to reduce the level of solids in the water coming from industrial, semiconductor, manufacturing, refining, or even processes like oil and natural gas production. The wastewater may contain chemicals that are harmful to humans, plants, or animals. There are three types of filters that are commonly used in industrial settings: Gravity filters, pressure filters, and constructed wetlands. Pressure filters have two variations which include multimedia and higher-pressure micron or cartridge filters. Constructed wetland or natural filters are not often utilized in industrial applications based upon the requirements to obtain environmental permits and to safeguard the ecosystem.



There are many benefits to pressure filtering industrial wastewater. Pressure filters can remove particles down to 0.3 microns in size, they don't clog up as easily as other filter types, and it's much faster than other types of filtration methods. Pressure filtering is also very cost-effective because it uses less energy than other methods do. If you're looking for a high-quality industrial water filter, look no further!



Pressure Filters  (Multimedia type) are often used in industrial settings to remove particles down to 15 microns in size. They're also very cost-effective due to the amount of energy they use; pressure filter utilize much less energy than other filtration methods. Pressure filters can include multimedia which is a mixture of gravel and sand, multimedia that combines gravel, sand, and anthracite, or multimedia that combines gravel, sand, greensand, and anthracite. The variations are dependent on the applications and the need.

Read More

Topics: water quality, water treatment, water plant, media packing, ION Exchange Resin, RO system, Pressure filter, Sand filters, Filter Media, industrial facilities, green sand, Gravity Filters, Constructed Wetlands

What Technology to use to Remove Per- & Polyfluorinated Substances

Posted by Anthony DeLoach, President on Dec 14, 2021 1:00:00 PM

Per-and polyfluorinated substances (PFAS) have been used for decades in many consumer products, and they are man-made and have a high residual time in the environment. These chemicals are used for various purposes, including nonstick surfaces, heat protection of circuits, water resistance, fighting fire as they are utilized in fire depression foam, and many other industrial applications. The difficult thing about PFAS is that the very reason they work so well on so many manufactured products is why they are so challenging to get rid of or treat once they have entered the environment or water supply. PFAS are being more and more regulated, and requirements are being put in place by many states and agencies to require the treatment and removal of PFAS and safeguard and protect drinking water.

PFAS are soluble in water, and they are not a volatile organic chemical (VOC), so traditional treatment methods such as utilizing an air stripping tower or degasification system are not effective methods to remove PFAS. One of the first technologies to remove PFAS from drinking water and the environment is activated carbon absorption. In recent years, utilizing ion exchange resins has proven effective and is gaining popularity for the treatment method. Ion exchange resins attach and bond with the PFAS and remove it effectively from the water. Some chemicals tested and studied with success include perfluorooctanoic acid (PFOS). In addition to these technologies, reverse osmosis utilizing high-pressure membranes has an 80-90% effective rate and has proven to be technically efficient in removing PFAS. An R.O. process produces a concentrated waste stream.

Read More

Topics: degasification, water treatment, advanced treatment solutions, water plant, ION Exchange Resin, wastewater, RO system, Deagasification

Using Aeration To Remove Iron from Water!

Posted by Anthony DeLoach, President on Oct 22, 2021 1:00:00 PM

Converting Ferrous (Fe+2) (soluble) iron to Ferric (Fe+3) (Particulate/Solid form).

The iron must first be exposed to air or another form of an oxidizing agent. Aeration is the most cost-effective method to oxidize ferrous iron for its removal from water. In many areas around the globe, municipal and industrial operations have the need to remove naturally occurring iron (Fe) from the water to both prevent damage to other equipment as well as to improve water quality. To remove iron from the water it first must be oxidized using the most widely accepted and cost-effective method called aeration. The aeration process changes the iron from its Ferrous (Fe+2) state (soluble) to ferric (Fe+3) a colloidal participate. Did you know that Iron occurs naturally and is found in the earth’s crust? It occurs in both groundwater as well as surface waters and is not known to cause any harmful effects on humans or animals.

Iron does cause problems though for municipal facilities and their customers by impacting laundry operations, causing stains on buildings, on plumbing fixtures. Iron also promotes and facilitates the growth of iron bacteria in water that creates a problem for distribution lines and piping systems. Once the lines become blocked this impacts the ability to distribute water to the customer. The presence of iron bacteria also becomes detectible even at low concentrations and impacts the taste of the water. The U.S Public Health Service Drinking Water Standard set a recommend maximum level of 0.3 mg/L in public water supplies.

Read More

Topics: aeration, Ferrous Iron, Iron

Decarbonation the Removal of CO2 from Water

Posted by Anthony DeLoach, President on Aug 16, 2021 2:08:54 PM

The basics of water decarbonation, the removal of CO2 from water

the removal of carbon dioxide (CO2). The need to remove (CO2) is essential in most Aquaculture, Municipal, Industrial, and Food & Beverage Processes To understand you must familiarize yourself with Henry’s Law.

Henry's Law defines the method and proportional relationship between the amount of a gas in solution

in relationship to the gases partial pressure in the atmosphere. Often you will see and hear various terms like degasification, decarbonation, aeration, and even air stripping when discussing the removal of dissolved gases and other convertible elements from water. Understanding the impacts that Carbon Dioxide (CO2) can have on both equipment and aquatic life provides the basic reasons why the need to decarbonate water, exists. Carbon Dioxide (CO2) can exist naturally in the raw water supply or be the results of ph control and balance. In either case the the process called Decarbonation or Degasification provide the most cost effective and efficient manner to reduce or tally remove (CO2) from the water. In addition to Carbon Dioxide (CO2), water can contain a variety of other contaminants that may impact the removal efficiency of the Carbon Dioxide. A variety of elements as well as dissolved gases such as oxygen, nitrogen and carbon dioxide (CO2). A full analytical review of the water chemistry is required to properly design and size the “Water Treatment” process.

Breaking the bonds in water to release a dissolved gas

such as carbon dioxide (CO2) you must change the conditions of the vapor pressure surrounding the gas and allow the gas to be removed.  There are many variables to consider when designing or calculating the “means and methods” of the removal of carbon dioxide (CO2). When I refer to the means and methods. I am referring to the design of a decarbonator and its components. The means equals the size and type (Hydraulic load) of the decarbonator and the “method” equals the additional variables such as cubic foot of air flow (CFM) and “Ratio” of the air to water to accomplish the proportional condition needed to remove the carbon dioxide (CO2).

Read More

Topics: water treatment issues, degasification, pH levels of water, aeration, iron oxidation, water treatment, water plant, bicarbonate, hydrogen sulfide (H2S), pH levels, Decarbonation, ION Exchange Resin, dissolved gases, De-Aeration, wastewater, carbon dioxide, oxygen, decarbonator, degasifier, gases, carbonic acid, H2S Degasifier, removal of CO2 from water

Biological Odor Control Scrubber

Posted by Anthony DeLoach, President on Aug 4, 2021 9:26:05 AM

A BIOLOGICAL ODOR CONTROL SCRUBBER IS JUST ONE OF MANY DIFFERENT TYPES OF AVAILABLE TECHNOLOGIES

To treat air emissions that may contain harmful gases. This class of equipment commonly falls into a category referred to as “Odor Control Scrubbers” and they are utilized to remove dangerous or noxious odors from an air stream. The Biological Odor Control System has gain popularity among many end users such as municipal operators due to the reduced operating cost and more simplistic operating requirements. A typical chemical odor control scrubber often requires two or more chemical additives, and more instrumentation is required to maintain system performance. With the additional chemicals required and instrumentation comes the need for more hands-on maintenance, calibration, and safety requirements which increases the operating costs and workload of the operator.

A Biological Odor Control System relies on active bacteria cultures that recirculate within a water stream and flow across a random packed media bed that is beneficial to the bacteria culture. During the process of metabolizing harmful gases such as Hydrogen Sulfide (H2S) the biological odor control system requires only the addition of Caustic to control and balance the pH and additional water makeup to replace what has been consumed through evaporation or during the blow down process to eliminate solids. There are several different types of odor control and chemical wet scrubbers on the market today and each provide a solution for the treatment of noxious or corrosive gases and odors in the industry.  And even though Biological scrubbers are commonly utilized in municipal applications for the treatment of hydrogen sulfide (H2S) gases that were produced by a water or wastewater treatment process there are times when a Biological Scrubber does not provide the best solution for treatment. When there are wide or rapidly changing concentration in the ppm (parts per million) level than a Biological Scrubber will have difficulties balancing and acclimating fast enough to prevent break through.  As an example, In water treatment there is a treatment process referred to as “degasification” which strips the hydrogen sulfide gas from the water and then the concentrated H2S gas is exhausted from the tower through an exhaust port.  When the concentration rises above 1 ppm for hydrogen sulfide gas then the levels become both noxious to the surroundings as well as corrosive. Many times, the levels range from 3-7 PPM in concentration with Hydrogen Sulfide and pose a serious health threat, noxious odor, and corrosive environment demanding capture and treatment. When utilizing an Odor Control Scrubber such as a Biological Scrubber the gases are pulled or pushed through an air duct system that is connected to the Biological Scrubber inlet or suction side of the blower. The same process is utilized when treating Hydrogen Sulfide (H2S) gases that were captured at a wastewater treatment process. These gases may have been generated from a source such as the wastewater treatment plant, lift station or master head-works facility. When captured the gases are also conveyed in a similar manner to the Biological Odor Control Tower for treatment.

So how does a Biological Scrubber work?

A Biological Odor Control Scrubber is in fact a eco system all to itself. The biological scrubber relies upon an initial seeding of tiny microorganisms (bacteria) which attach themselves to the internal media substrate or packing providing both a place to attach and to breed and multiply all the time coming in direct contact with the contaminated air. The bacteria are utilized to breakdown and digest contaminants, and it feeds on the contaminants as a food source which allows it to not only live but continue to grow and multiply.

When utilizing a Biological Odor Scrubber for hydrogen sulfide (H2S) treatment and removal the by-product that is produced during the reaction is a waste in the form of Sulphuric Acid which is produced as the Sulphur is consumed as a food source. The Sulphuric acid waste lowers the pH of the recirculating water and can create an unhealthy

Read More

Topics: water treatment issues, degasification, odor control, water treatment, advanced treatment solutions, biological scrubber, odor control scrubber, hydrogen sulfide (H2S), Chemical Odor, media packing, caustic, wastewater, gases, H2S Degasifier, Ammonia

Water Degasification in Pisciculture

Posted by Anthony DeLoach, President on Feb 11, 2020 9:36:29 AM

The need to remove harmful elements from water such as Hydrogen Sulfide and Carbon Dioxide

from water in the pisciculture and aquaculture market is extremely important. In order to achieve maximum results, the industry utilizes a treatment technology called “Degasificationand controls the pH precisely to maximize results. When utilizing equipment such as the DeLoach Industries degasification systems the hydrogen sulfide and carbon dioxide levels can be removed to 99.999% ug/l.

pH control with water degasification in water treatment is very important for the aquaculture and the pisciculture market. In addition, there are a host of other organic and inorganic elements found in water both naturally occurring and manmade that require removal during some part of the water treatment process and pH plays a significant role on the effectiveness of the treatment process.

Every application of degasification depends on pH adjustment to maximize results. As an example, the treatment of water may require the removal of hydrogen sulfide (H2S) to protect the species during the growth period. Hydrogen sulfide can be removed either as a “free” gas or requires the conversion of sulfides into (H2S) as a gas they you will quite often also see the need to adjust pH of the water chemistry to maximize both the removal and the conversion to increase the efficiency of the equipment being utilized to remove the hydrogen sulfide such as a degasification tower or commonly called a degasifier.

Read More

Topics: water treatment issues, water quality, degasification, pH levels of water, water treatment, advanced treatment solutions, hydrogen sulfide (H2S), pH levels, Decarbonation, carbon dioxide, oxygen, decarbonator, degasifier, H2S Degasifier, Aqua Farming, Fish Farming, Aquaculture, Pisciculture

Relationship of Water Degasification and Decarbonation and pH

Posted by Anthony DeLoach, President on Feb 3, 2020 1:01:00 PM

The need for pH control with water degasification and decarbonation in water treatment includes almost every industry and includes;

aquaculture, food and beverage, industrial, municipal, and even pisciculture.  In some water treatment applications, there are harmful gases such as Hydrogen Sulfide (H2S) being removed while in other applications Carbon Dioxide (CO2) or even a combination of both. In addition, there are a host of other organic and inorganic elements found in water both naturally occurring and manmade that require removal during some part of the water treatment process.

In almost every application of Degasification of Decarbonation you will hear or see the term pH used either by need or by result.  If as an example the water treatment application is requiring the removal of Hydrogen Sulfide (H2S) be removed either as a “free” gas or requires the conversion of Sulfides into (H2S) as a gas they you will quite often also see the need to adjust pH of the water chemistry to maximize both the removal and the conversion to increase the efficiency of the equipment being utilized to remove the Hydrogen Sulfide such as a Degasification Tower or commonly called a Degasifier.

Read More

Topics: water treatment issues, water quality, degasification, pH levels of water, odor control, water treatment, advanced treatment solutions, hydrogen sulfide (H2S), Chemical Odor, pH levels, Decarbonation, dissolved gases, carbon dioxide, degasifier, gases, H2S Degasifier, Aqua Farming, Fish Farming, Aquaculture

Degasification for Pisciculture

Posted by Anthony DeLoach, President on Jul 23, 2019 11:03:53 AM

To enhance and balance the water quality

in aquaculture and pisciculture operations, the industry is recognizing the benefits from utilizing a type of water treatment called “Forced Draft Degasification” to remove CO2 (Carbon Dioxide) and H2S (Hydrogen Sulfide) gases and oxidize other elements such as Iron or Magnesium.

Removing these elements from the water process improves the quality of the water and aids in the balancing of the pH without the need for additional chemicals. This also reduces the risk of unnecessary and preventable loss of life to your aqua farming  project.  Keeping the ph at the proper level will enable a good healthy environment and will prevent further problems that may occur due to the ph is not kept in a stable state.

Not all degasification towers are equal!

The market has seen an influx of low efficiency performance systems which why they may offer a low capital entry point for a customer they fall short on providing the overall quality enhancements a properly design degasification tower provides. Utilizing low efficient perforated trays with natural updraft will result in low removal efficiencies of CO2 and H2S gases.

There are additional benefits that are achieved when a properly designed and sized degasification tower is selected for aquaculture water enhancement which include the ability to remove excess heat from the water and stabilize a temperature from the effluent of the tower. In order for your system to maintain its efficiency it is important to design the proper tower for your needs. In addition, the oxidation of iron with enhance enrichment of O3 (Oxygen) and complete conversion and removal of CaCO3 (Calcium- Carbonate). A properly sized degasification tower or Decarbonation tower if your goal is to only remove CO2 will utilize a loose fill media packing bed, a header lateral distribution system with nozzles, media support plates, de-mister, and a forced draft type blower capable of overcoming the required static pressure.

Read More

Topics: De-Aeration, carbon dioxide, decarbonator, degasifier, gases, H2S Degasifier, Aqua Farming, Fish Farming, Aquaculture, Pisciculture

Hydrogen Sulfide Scrubber (with audio)

Posted by Anthony DeLoach, President on Jun 28, 2019 2:48:10 PM
Hydrogen Sulfide Scrubber (audio)

Hydrogen Sulfide Chemical Formula and the Molar mass of H2S

What is hydrogen sulfide? H2S is a naturally occurring chemical compound that is created in nature with the decay of organic material. Hydrogen sulfide formula is a chemical compound with a molecular formula comprised of (2) hydrogen atoms and (1) one sulfur atom. The formula is displayed as H2S. The gas is a colorless hydride gas and it is often known as the “Rotten egg gas”. This gas is very dangerous as it is poisonous and toxic to all forms of life. It is also very corrosive and flammable. The H2S molar mass is 34.1 g/mol and it has a melting point of -76 F (-60 C) and a melting point of –115.6F or (-82C).

Hydrogen sulfide gas is also created more often from a byproduct of a manufacturing process or from the removal of water or waste water treatment systems. In waste water as organic material decays H2S is released,  captured and treated to protect human lives, reduce corrosion, and reduce odor complaints. During the manufacturing operations at refineries, pulp mills, and mining hydrogen sulfide gas is produced. These higher levels of H2S are released during the manufacturing process and must be captured and neutralized to protect human life and prevent excessive corrosion.  At higher concentration you cannot even smell the gas and it is not distinguishable as the “rotten egg gas” which makes it even more dangerous and drives the need for the equipment known as hydrogen sulfide scrubbers, fume scrubbers, or odor control scrubbers.

According to the “Agency for Toxic Substance & Disease Registry those who work within certain industries, are exposed daily to higher levels of hydrogen sulfide gas than the normal public. Because the gas is also heavier than air it will settle into lower places like manholes, tanks, basements and it will travel across the ground filling in low level areas. To protect the public OSHA has set guidelines and rules known as “Permissible Exposure Limits” (PEL). A PEL is the legal limit a worker may be exposed to a chemical substance. The PEL limit for hydrogen sulfide is ten parts per million (10 ppm) over an eight-hour period.

Read More

Topics: water treatment issues, degasification, odor control, water treatment, advanced treatment solutions, odor control scrubber, hydrogen sulfide (H2S), Chemical Odor, dissolved gases, wastewater, decarbonator, degasifier, gases, H2S Degasifier, Hydrogen Sulfide Chemical Formula, Molar mass, Hydrogen Sulfide formula, molar mass h2s

Water Treatment Compliance with NSF/ANSI 61 Certification (with audio)

Posted by Anthony DeLoach, President on Jun 12, 2019 10:24:13 AM
WATER TREATMENT COMPLIANCE WITH NSFANSI 61 certification (audio)



The process of Decarbonation requires

the use of a vertically designed Degasification tower. A Decarbonation tower is specifically design

ed to remove Carbon Dioxide (CO2) from a water treatment process. When the water is being treated for “potable” use for direct or indirect consumption than all of the components used in the process must comply with NSF/ANSI 61 standard to assure that the components that have direct contact with the water are safe and will not introduce any foreign substance during the treatment process. Decarbonation towers have direct exposure and contact with the water during the removal of CO2 and therefore must be manufactured from material such as Fiberglass (FRP) that complies and meets the NSF/ANSI 61 standard.

Read More

Topics: water treatment, NSF/ANSI 61, Safe drinking water
